We are WEE, We Enhance Efficiency

Year Established: 2000

Headquarter: Hongkong

Employees: 500

Products: General Purpose Rectifier, Fast Recovery Rectifier, Transient Voltage Suppressor, Schottky Rectifier, Switching Diode, Zener Diode...

Application: Automotive, Consumer, Computer, Lighting, Communication, Energy Harvesting, and Smart Grid...

Market: America, Europe, Asia, South Africa and Mid. East...

Advantages: Considerate Service, Competitive Offer, Credible Quality & Lead Time...

Catalogue: https://www.weediode.com/zb_users/upload/2020/10/WEETechnologyCompanyLimitedCatalogueDiodeRectifierTransistor.pdf

Presentation: https://www.weediode.com/WEE-Technology-Company-Limited-Presentation.pdf

REACH: https://www.weetcl.com/pdf/WEE-Technology-Diodes-Rectifiers-RoHS-II-2023.pdf

ROHS: https://weetcl.com/pdf/WEE-Technology-Diodes-Rectifiers-REACH-2023.pdf

Wechat: WEETCHINA

Whatsapp: +86 176 7621 4359

Email, Teams: info@weediode.com

Website: http://www.weetcl.com/

Written by WEE Technology Company Limited

We are WEE, We Enhance Efficiency

WEET LL-34 LL4148 Fast Switching Diode Minimelf SOD80

1N4148 is a glass-sealed in-line diode, the package is DO-35; the plastic-sealed is 1N4148W or called T4, the package is SOD-123; LL4148 is MINI MELF package, cylindrical leadless, also glass-seald.

1N means that the device has a PN junction, similar to the US-made triodes which start with 2N because the triode has two PN junctions. LL4148 is a SMD version of 1N4148.

Check more LL4148 LL-34 information at https://www.weetcl.com/High_Speed_Switching_Diodes/LL34_LL4148.html
datasheet: https://www.weetcl.com/pdf/WEET_LL34_LL4148.pdf

Skype, Email: info@weediode.com
Written by WEE Technology Company Limited

We are WEE, We Enhance Efficiency

WEET 1.0 AMPS. MB1F THRU MB10F Glass Passivated Bridge Rectifiers
MB1F(50V),MB2F(100V),MB3F(200V),MB4F(400V),MB6F(600V),MB8F(800V),MB10F(1000V)

MB1F, MB2F, MB3F, MB4F, MB6F, MB8F, MB10F are designed for smaller, thinner and lower energy application circuits. They are ideal for trendy electronic products. The soldering pins are the same as MB6S. It can be directly replaced in the case of changing the PCB board, which is very helpful for the development of the production industry of miniaturized high current products, and is very suitable for portable applications that save board space design!

MBF product application range:
LED lighting control circuit, energy saving lamp circuit board control, fluorescent lamp, car light, IP voice, modem, power over Ethernet, laptop, network equipment, data line protection, line card, switch mode power supply, power conversion, and any small demand high-energy bridge rectifier circuit.

Check more MB1F, MB2F, MB3F, MB4F, MB6F, MB8F, MB10F information at https://www.weetcl.com/Single_Phase_Bridge_Rectifiers/WEE_MBF_MB1F_THRU_MB10F.html

datasheet: https://www.weetcl.com/pdf/WEET_MBF_MB1F_THRU_MB10F.pdf

Skype, Email: info@weediode.com
Written by WEE Technology Company Limited

We are WEE, We Enhance Efficiency

WEET 1.0 AMPS. MB1F THRU MB6F Glass Passivated Bridge Rectifiers
MB1F(50V),MB2F(100V),MB3F(200V),MB4F(400V),MB6F(600V)

MB1F, MB2F, MB3F, MB4F, MB6F is packaged in MBF, surface mounted, mainly used in small current field products, small power switching power supply, power adapter, LED light source circuit, charger, electric fan, TV, household appliances And other related electrical products.

Check more MB1F, MB2F, MB3F, MB4F, MB6F information at https://www.weetcl.com/Single_Phase_Bridge_Rectifiers/WEE_MBF_MB1F_THRU_MB10F.html
datasheet: https://www.weetcl.com/pdf/WEET_MBF_MB1F_THRU_MB10F.pdf

Skype, Email: info@weediode.com
Written by WEE Technology Company Limited

We are WEE, We Enhance Efficiency

WEET 1.0 AMPS. MB1S THRU MB6S Glass Passivated Bridge Rectifiers
MB1S(50V),MB2S(100V),MB3S(200V),MB4S(400V),MB6S(600V)

The bridge rectifier MB6S and MB8S do not have a fixed output voltage, the output voltage is determined according to the input voltage, and the withstand voltage values of that component are 600V and 800V, respectively;
The bridge rectifier is to seal the rectifier in a shell. Divided into full bridge and half bridge. The full bridge seals the four diodes of the connected bridge rectifier circuit. The half bridge is to seal together half of the two diode bridge rectifiers. Two bridges can be used to form a bridge rectifier circuit. One half bridge can also form a full-wave rectifier circuit with a center tap of the transformer. Rectifier circuit and working voltage

Check more MB1S, MB2S, MB3S, MB4S, MB6S information at https://www.weetcl.com/Single_Phase_Bridge_Rectifiers/WEE_MBS_MB1S_THRU_MB10S.html
datasheet: https://www.weetcl.com/pdf/WEET_MBS_MB1S_THRU_MB10S.pdf

Skype, Email: info@weediode.com
Written by WEE Technology Company Limited

We are WEE, We Enhance Efficiency

WEET 1.0 AMPS. MB1S THRU MB10S Glass Passivated Bridge Rectifiers
MB1S(50V),MB2S(100V),MB3S(200V),MB4S(400V),MB6S(600V),MB8S(800V),MB10S(1000V)

The function of MB10S bridge rectifier is to work through the diode's unidirectional conduction principle. In general, the diode is forward-conducting and reverse-cut, that is, the diode only allows its positive pole to be positive and negative pole to be negative. The diode only allows the current to pass in one direction, so when it is connected to the AC circuit, it can make the current in the circuit flow only in one direction, so-called "rectification", with two tubes being half-pumped rectification, and four tubes being full-flow rectification.

Convert AC power to DC power, including half-wave rectification, full-wave rectification, and bridge rectification. The bridge rectifier encapsulates the four diodes of the bridge rectification and draws only four pins. Of the four pins, two DC outputs are labeled + or -, and the two AC inputs have a ~ mark. Apply the rectifier bridge to the circuit, mainly considering its maximum operating current and maximum reverse voltage.

Check more MB1S, MB2S, MB3S, MB4S, MB6S,MB8S,MB10S information at https://www.weetcl.com/Single_Phase_Bridge_Rectifiers/WEE_MBS_MB1S_THRU_MB10S.html
datasheet: https://www.weetcl.com/pdf/WEET_MBS_MB1S_THRU_MB10S.pdf

Skype, Email: info@weediode.com
Written by WEE Technology Company Limited

We are WEE, We Enhance Efficiency

WEET R-6 6A05 THRU 6A10 General Purpose Plastic Rectifier
6A05(50V),6A1(100V),6A1(200V),6A4(400V),6A4(600V),6A8(800V),6A10(1000V)

6A10 is a diode rectifier, a semiconductor device that converts AC power into DC power. Usually it contains a PN junction with two terminals, anode and cathode.
Maximum average rectified current IF: 6A
The highest reverse working voltage VR: 1000V

Check more 6A05, 6A1, 6A2, 6A4, 6A6, 6A8, 6A10 information at https://www.weetcl.com/General_Purpose_Rectifiers/R6_6A05_THRU_6A10.html
datasheet: https://www.weetcl.com/pdf/WEET_R6_6A05_THRU_6A10.pdf

Skype, Email: info@weediode.com
Written by WEE Technology Company Limited

We are WEE, We Enhance Efficiency

WEET SMA(DO-214AC) ER2A THRU ER2J Ultra-Fast Recovery Rectifiers
ER2A(50V),ER2B(100V),ER2C(150V),ER2D(200V),ER2E(300V),ER2G(400V),ER2J(600V)

Fast recovery diodes are also commonly used as graphical symbols for common diodes, either by text or by model. The fast recovery diode is similar to a normal diode, but the manufacturing process is different from that of a normal one. The doping concentration near the PN junction is very low, resulting in a higher switching speed and a lower forward voltage drop.
Compared with Schottky diodes, the withstand voltage is much higher. It is mainly used as a high-speed rectifying component, which is used as a rectifying transistor in switching power supplies and inverter power supplies to reduce turn-off loss, improve efficiency and reduce noise.

Check more ER2A, ER2B, ER2C, ER2D, ER2E, ER2G, ER2J information at https://www.weetcl.com/Ultra_Fast_Recovery_Rectifiers/SMA_ER2A_THRU_ER2J.html
datasheet: https://www.weetcl.com/pdf/WEET_SMA_ER2A_THRU_ER2J.pdf

Skype, Email: info@weediode.com
Written by WEE Technology Company Limited

We are WEE, We Enhance Efficiency

Global semiconductor industry posted sales totaling $335.2 billion in 2015, a slight decrease of 0.2 percent compared to the 2014 total, which was the industry’s highest-ever sales total. Global sales for the month of December 2015 reached $27.6 billion, down 4.4 percent compared to the previous month and 5.2 percent lower than sales from December 2014. Fourth quarter sales of $82.9 billion were 5.2 percent lower than the total of $87.4 billion from the fourth quarter of 2014.

Several semiconductor product segments stood out in 2015. Logic was the largest semiconductor category by sales with $90.8 billion in 2015, or 27 percent of the total semiconductor market. Memory ($77.2 billion) and micro-ICs ($61.3 billion) – a category that includes microprocessors – rounded out the top three segments in terms of total sales. Optoelectronics was the fastest growing segment, increasing 11.3 percent in 2015. Other product segments that posted increased sales in 2015 include sensors and actuators, which reached $8.8 billion in sales for a 3.7 percent annual increase, NAND flash memory ($28.8 billion/2.2 percent increase), and analog ($45.2 billion/1.9 percent increase).

Regionally, annual sales increased 7.7 percent in China, leading all regional markets. All other regional markets – the Americas (-0.8 percent), Europe (-8.5 percent), Japan (-10.7 percent), and Asia Pacific/All Other (-0.2 percent) – saw decreased sales compared to 2014.

Email,Skype: info@weediode.com

Written by WEE Technology Company Limited

We are WEE, We Enhance Efficiency

WEET SMA 400W SMAJ Series Transient Voltage Suppessor

SMAJ5.0A SMAJ5.0CA
SMAJ6.0A SMAJ6.0CA
SMAJ6.5A SMAJ6.5CA
SMAJ7.0A SMAJ7.0CA
SMAJ7.5A SMAJ7.5CA
SMAJ8.0A SMAJ8.0CA
SMAJ8.5A SMAJ8.5CA
SMAJ9.0A SMAJ9.0CA
SMAJ10A SMAJ10CA
SMAJ11A SMAJ11CA
SMAJ12A SMAJ12CA
SMAJ13A SMAJ13CA
SMAJ14A SMAJ14CA
SMAJ15A SMAJ15CA
SMAJ16A SMAJ16CA
SMAJ17A SMAJ17CA
SMAJ18A SMAJ18CA
SMAJ20A SMAJ20CA
SMAJ22A SMAJ22CA
SMAJ24A SMAJ24CA
SMAJ26A SMAJ26CA
SMAJ28A SMAJ28CA
SMAJ30A SMAJ30CA
SMAJ33A SMAJ33CA
SMAJ36A SMAJ36CA
SMAJ40A SMAJ40CA
SMAJ43A SMAJ43CA
SMAJ45A SMAJ45CA
SMAJ48A SAMJ48CA
SMAJ51A SMAJ51CA
SMAJ54A SMAJ54CA
SMAJ58A SMAJ58CA
SMAJ60A SMAJ60CA
SMAJ64A SMAJ64CA
SMAJ70A SMAJ70CA
SMAJ75A SMAJ75CA
SMAJ78A SMAJ78CA
SMAJ85A SMAJ85CA
SMAJ90A SMAJ90CA
SMAJ100A SMAJ100CA
SMAJ110A SMAJ110CA
SMAJ120A SMAJ120CA
SMAJ130A SMAJ130CA
SMAJ150A SMAJ150CA
SMAJ160A SMAJ160CA
SMAJ170A SMAJ170CA
SMAJ180A SMAJ180CA
SMAJ200A SMAJ200CA
SMAJ220A SMAJ220CA
SMAJ250A SMAJ250CA
SMAJ300A SMAJ300CA
SMAJ350A SMAJ350CA
SMAJ400A SMAJ400CA
SMAJ440A SMAJ440CA

Check more SMAJ5.0A,SMAJ6.0A,SMAJ6.5A,SMAJ7.0A...MAJ440CA information at https://www.weetcl.com/Transient_Voltage_Suppressors/SMA_SMAJ_Series.html
datasheet: https://www.weetcl.com/pdf/WEET_SMA_SMAJ_Series.pdf

Skype, Email: info@weediode.com
Written by WEE Technology Company Limited

We are WEE, We Enhance Efficiency

WEET SMA(DO-214AC) SS12 THRU SS120 Surface Mount Schottky Barrier Rectifier SS12(20V),SS14(40V),SS15(50V),SS16(60V),SS18(80V),SS110(100V),SS115(150V),SS120(200V)

FEATURES
Low profile surface mount package
Built-in strain relief
High switching speed
Low voltage drop, high efficiency
For use in low voltage high frequency inverters, Free willing, and polarity protection applications
Guarding for over voltage protection

MECHANICAL DATA
Case: Transfer molded plastic
Epoxy: UL 94V-0 rate flame retardant
Lead: Solder plated, solderable per MIL-STD-750 method 2026
Polarity: Color band denotes cathode end
Weight: 0.002 ounce, 0.064 gram

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25°C ambient temperature unless otherwise specified.
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load derate current by 20%.

Check more SS12, SS14, SS15, SS16, SS18, SS110, SS115, SS120 information at https://www.weetcl.com/Schottey_Barrier_Rectifiers/SMA_SS12_THRU_SS120.html
datasheet: https://www.weetcl.com/pdf/WEET_SMA_SS12_THRU_SS120.pdf

Skype, Email: info@weediode.com
Written by WEE Technology Company Limited

We are WEE, We Enhance Efficiency

WEET SMA-J(DO-214AC) ES1A THRU ES1J Ultra-Fast Recovery Rectifiers
ES1A(50V),ES1B(100V),ES1C(150V),ES1D(200V),ES1G(400V),ES1J(600V)

Maximum Average Forward Rectified Current at TA=55°C: 1.0 Amps
Peak Forward Surge Current 8.3mS single half sine-wave superimposed on rated load(JEDEC method): 30Amps
Maximum DC Reverse Current at Rated DC Blocking Voltage (TA= 25°C) : 5.0μA
Maximum DC Reverse Current at Rated DC Blocking Voltage (TA= 100°C) : 30μA
Maximum Reverse Recovery Time(NOTE1): 35ns
Typical Junction Capacitance (NOTE 2): 15pF
Typical Thermal Resistance (NOTE 3): 55°C/W
Operating and Storage Temperature Range:-55 to +150°C

Check more ES1A, ES1B, ES1C, ES1D, ES1E, ES1G, ES1J information at https://www.weetcl.com/search/?Submit=&keyword=ES1J
datasheet: https://www.weetcl.com/pdf/WEET_SMAJ_ES1A_THRU_ES1J.pdf

Skype, Email: info@weediode.com
Written by WEE Technology Company Limited

We are WEE, We Enhance Efficiency

WEET SMA-J(DO-214AC) ES1A THRU ES1J Ultra-Fast Recovery Rectifiers
ES1A(50V),ES1B(100V),ES1C(150V),ES1D(200V),ES1G(400V),ES1J(600V)

WEET diode rectifier mainly solves unique applications in the automotive industry, consumer electronics, communications, military, aerospace, solar energy, and medical industries. It mainly provides high-power and high-wattage semiconductor circuit design components to meet market demands. All types of products have a complete sales system, which can provide products to customers in a timely and effective manner.

Check more ES1A, ES1B, ES1C, ES1D, ES1E, ES1G, ES1J information at https://www.weetcl.com/search/?Submit=&keyword=ES1J
datasheet: https://www.weetcl.com/pdf/WEET_SMAJ_ES1A_THRU_ES1J.pdf

Skype, Email: info@weediode.com
Written by WEE Technology Company Limited

We are WEE, We Enhance Efficiency

WEET SMA-J RS1A THRU RS1M Surface Mount Fast Recovery Rectifier
RS1A(50V),RS1B(100V),RS1D(200V),RS1G(400V),RS1J(600V),RS1K(800V),RS1M(1000V)

Maximum Average Forward Rectified Current at TA=55°C: 1.0 Amps
Peak Forward Surge Current 8.3mS single half sine-wave superimposed on rated load(JEDEC method): 30Amps
Maximum  Instantaneous Forward Voltage at 1.0A: 1.3 Volts
Maximum DC Reverse Current at Rated DC Blocking Voltage (TA= 25°C) : 5.0μA
Maximum DC Reverse Current at Rated DC Blocking Voltage (TA= 100°C) : 100μA
Maximum Reverse Recovery Time: 150 nS for RS1A, RS1B, RS1D, RS1G; 250 nS for RS1J; 500 nS forR S1K, RS1M

Typical Junction Capacitance: 20pF
Typical Thermal Resistanc: 55°C/W
Operating and Storage Temperature Range:-55 to +150°C

Check more RS1A, RS1B, RS1D, RS1G, RS1J, RS1K, RS1M information at https://www.weetcl.com/Fast_Recovery_Rectifiers/SMAJ_RS1A_THRU_RS1M.html
datasheet: https://www.weetcl.com/pdf/WEET_SMAJ_RS1A_THRU_RS1M.pdf

Skype, Email: info@weediode.com
Written by WEE Technology Company Limited

We are WEE, We Enhance Efficiency

WEET SMAJ(DO-214AC) SS22 THRU SS210 Surface Mount Schottky Barrier Rectifier
SS22(20V),SS23(30V),SS24(40V),SS25(50V),SS26(60V),SS28(80V),SS29(90V),SS210(100V)

Maximum Average Forward Rectified Current at TLsee figure 1 TL =105℃: 2.0 Amps
Peak Forward Surge Current 8.3mS single half sine-wave superimposed on rated load(JEDEC method): 50Amps
Maximum Instantaneous Forward Voltage at2.0A: 0.55 Volts for SS22,SS23,SS24;0.70 Volts for SS25,SS26;0.85 Volts for SS28,SS29,SS210
Maximum DC Reverse Current at Rated DC Blocking Voltage per element(TA= 25°C) : 0.5μA
Maximum DC Reverse Current at Rated DC Blocking Voltage per element(TA= 100°C) : 20.0μA 10.0μA
Typical Thermal Resistance RθJA: 55°C/W
Typical Thermal Resistance RθJL: 12°C/W
Operating and Storage Temperature Range:-55 to +125°C

Check more SS22, SS23, SS24, SS25, SS26, SS28, SS210 information at https://www.weetcl.com/Schottey_Barrier_Rectifiers/SMAJ_SS22_THRU_SS210.html
datasheet: https://www.weetcl.com/pdf/WEET_SMAJ_SS22_THRU_SS210.pdf

Skype, Email: info@weediode.com
Written by WEE Technology Company Limited

We are WEE, We Enhance Efficiency

WEET SMA-J US1A THRU US1M Surface Mount High Efficiency Rectifier
US1A(50V),US1B(100V),US1D(200V),US1G(400V),US1J(600V),US1K(800V),US1M(1000V)

Maximum Average Forward Rectified Current at TA=55°C: 1.0 Amps
Peak Forward Surge Current 8.3mS single half sine-wave superimposed on rated load(JEDEC method): 30Amps
Maximum  Instantaneous Forward Voltage at 1.0A: 1.3 Volts for US1A, US1B, US1D;1.3 Volts for US1G; 1.7 Volts for US1J, US1K, US1M
Maximum DC Reverse Current at Rated DC Blocking Voltage (TA= 25°C) : 5.0μA
Maximum DC Reverse Current at Rated DC Blocking Voltage (TA= 100°C) : 100μA
Maximum Reverse Recovery Time: 50 nS for US1A, US1B, US1D, US1G;75 nS for US1J, US1K, US1M
Typical Junction Capacitance: 20pF
Typical Thermal Resistance: 55°C/W
Operating and Storage Temperature Range:-55 to +150°C

Check more US1A, US1B, US1D, US1G, US1J, US1K, US1M information at https://www.weetcl.com/High_Efficiency_Rectifiers/SMAJ_US1A_THRU_US1M.html
datasheet: https://www.weetcl.com/pdf/WEET_SMAJ_US1A_THRU_US1M.pdf

Skype, Email: info@weediode.com
Written by WEE Technology Company Limited

We are WEE, We Enhance Efficiency

WEET SMAJ(DO-214AC) RS2A THRU RS2M Surface Mount Fast Recovery Rectifier
RS2A(50V),RS2B(100V),RS2D(200V),RS2G(400V),RS2J(600V),RS2K(800V),RS2M(1000V)

Maximum Average Forward Rectified Current at TL=90°C: 2.0 Amps
Peak Forward Surge Current 8.3mS single half sine wave superimposed on rated load(JEDEC method): 50Amps
Maximum  Instantaneous Forward Voltage at 1.5A: 1.3 Volts
Maximum DC Reverse Current at Rated DC Blocking Voltage (TA= 25°C) : 5.0μA
Maximum DC Reverse Current at Rated DC Blocking Voltage (TA= 125°C) : 50μA
Maximum Reverse Recovery Time: 150 nS for RS2A, RS2B, RS2D, RS2G;250 nS for RS2J;500 nS for RS2K, RS2M
Typical Junction Capacitance at 4.0V, 1MHz: 30pF forRS2B, RS2D, RS2G, RS2J; 7pF for RS2K, RS2M

Typical Thermal Resistance RθJA: 105°C/W
Typical Thermal Resistance RθJL: 32°C/W
Operating Junction and Storage Temperature Range:-55 to +150°C

Check more RS2A, RS2B, RS2D, RS2G, RS2J, RS2K, RS2M information at https://www.weetcl.com/Fast_Recovery_Rectifiers/SMA_RS2A_THRU_RS2M.html
datasheet: https://www.weetcl.com/pdf/WEET_SMA_RS2A_THRU_RS2M.pdf

Skype, Email: info@weediode.com
Written by WEE Technology Company Limited

We are WEE, We Enhance Efficiency

WEET SMB(DO-214AA) RS2A THRU RS2M Surface Mount Fast Recovery Rectifier
RS2A(50V),RS2B(100V),RS2D(200V),RS2G(400V),RS2J(600V),RS2K(800V),RS2M(1000V)

Maximum Average Forward Rectified Current at TL=90°C: 2.0 Amps
Peak Forward Surge Current 8.3mS single half sine wave superimposed on rated load(JEDEC method): 50Amps
Maximum  Instantaneous Forward Voltage at 1.5A: 1.3 Volts
Maximum DC Reverse Current at Rated DC Blocking Voltage (TA= 25°C) : 5.0μA
Maximum DC Reverse Current at Rated DC Blocking Voltage (TA= 125°C) : 50μA
Maximum Reverse Recovery Time: 150 nS for RS2A, RS2B, RS2D, RS2G;250 nS for RS2J;500 nS for RS2K, RS2M
Typical Junction Capacitance at 4.0V, 1MHz: 20pF for RS2A, RS2B, RS2D, RS2G; 17pF for RS2J, RS2K, RS2M
Typical Thermal Resistance RθJA: 55°C/W
Typical Thermal Resistance RθJL: 18°C/W
Operating Junction and Storage Temperature Range:-55 to +150°C

Check more RS2A, RS2B, RS2D, RS2G, RS2J, RS2K, RS2M information at https://www.weetcl.com/Fast_Recovery_Rectifiers/SMB_RS2A_THRU_RS2M.html
datasheet: https://www.weetcl.com/pdf/WEET_SMB_RS2A_THRU_RS2M.pdf

Skype, Email: info@weediode.com
Written by WEE Technology Company Limited

We are WEE, We Enhance Efficiency

WEET SMB(DO-214AA) ES2A THRU ES2J Ultra-Fast Recovery Rectifiers
ES2A(50V),ES2B(100V),ES2C(150V),ES2D(200V),ES2E(300V),ES2G(400V),ES2J(600V)

Maximum Average Forward Rectified Current at TL=100°C: 2.0 Amps
Peak Forward Surge Current 8.3mS single half sine wave superimposed on rated load(JEDEC method): 50Amps
Maximum  Instantaneous Forward Voltage at 2.0A: 0.95 Volts for ES2A, ES2B, ES2C, ES2D; 1.25 Volts for ES2E, ES2G; 1.7 Volts for ES2J
Maximum DC Reverse Current at Rated DC Blocking Voltage (TA= 25°C) : 5.0μA
Maximum DC Reverse Current at Rated DC Blocking Voltage (TA= 125°C) : 200μA
Maximum Reverse Recovery Time: 35 nS
Typical Junction Capacitance at 4.0V, 1MHz: 25pF for ES2A, ES2B, ES2C; 208pF for ES2D, ES2E, ES2G, ES2J
Typical Thermal Resistance RθJA: 75°C/W
Typical Thermal Resistance RθJL: 17°C/W
Operating Junction and Storage Temperature Range:-55 to +150°C

Check more ES2A, ES2B, ES2C, ES2D, ES2E, ES2G, ES2J information at https://www.weetcl.com/Ultra_Fast_Recovery_Rectifiers/SMB_ES2A_THRU_ES2J.html
datasheet: https://www.weetcl.com/pdf/WEET_SMB_ES2A_THRU_ES2J.pdf

Skype, Email: info@weediode.com
Written by WEE Technology Company Limited

We are WEE, We Enhance Efficiency

WEET SMB(DO-214AA) S2A THRU S2M Surface Mount General Purpose Plastic Rectifier
S2A(50V),S2B(100V),S2D(200V),S2G(400V),S2J(600V),S2K(800V),S2M(1000V)

Maximum Average Forward Rectified Current at TL=100°C: 2.0 Amps
Peak Forward Surge Current 8.3mS single half sine wave superimposed on rated load(JEDEC method): 50Amps
Maximum  Instantaneous Forward Voltage at 1.5A: 1.15 Volts
Maximum DC Reverse Current at Rated DC Blocking Voltage (TA= 25°C) : 5.0μA
Maximum DC Reverse Current at Rated DC Blocking Voltage (TA= 125°C) : 125μA
Typical Reverse Recovery Time at IF=0.5A, IR=1.0A, IRR=0.25A, Trr: 2.0μs
Typical Junction Capacitance at 4.0V, 1MHz: 30pF
Typical Thermal Resistance RθJA: 53°C/W
Typical Thermal Resistance RθJL: 16°C/W
Operating Junction and Storage Temperature Range:-55 to +150°C

Check more S2A, S2B, S2D, S2G, S2J, S2K, S2M information at https://www.weetcl.com/General_Purpose_Rectifiers/SMB_S2A_THRU_S2M.html
datasheet: https://www.weetcl.com/pdf/WEET_SMB_S2A_THRU_S2M.pdf

Skype, Email: info@weediode.com
Written by WEE Technology Company Limited

We are WEE, We Enhance Efficiency

WEET SMB(DO-214AA) S3A THRU S3M Surface Mount General Purpose Plastic Rectifier
S3A(50V),S3B(100V),S3D(200V),S3G(400V),S3J(600V),S3K(800V),S3M(1000V)

Maximum Average Forward Rectified Current at TL=100°C: 3.0 Amps
Peak Forward Surge Current 8.3mS single half sine wave superimposed on rated load(JEDEC method): 100Amps
Maximum  Instantaneous Forward Voltage at 3.0A: 1.10 Volts
Maximum DC Reverse Current at Rated DC Blocking Voltage (TA= 25°C) : 10.0μA
Maximum DC Reverse Current at Rated DC Blocking Voltage (TA= 125°C) : 250μA
Typical Reverse Recovery Time: 2.5μs
Typical Junction Capacitance: 60pF
Typical Thermal Resistance RθJA: 47°C/W
Typical Thermal Resistance RθJL: 13°C/W
Operating Junction and Storage Temperature Range:-55 to +150°C

Check more S3A, S3B, S3D, S3G, S3J, S3K, S3M information at https://www.weetcl.com/General_Purpose_Rectifiers/SMB_S3A_THRU_S3M.html
datasheet: https://www.weetcl.com/pdf/WEET_SMB_S3A_THRU_S3M.pdf

Skype, Email: info@weediode.com
Written by WEE Technology Company Limited
