[置顶] WEE TECHNOLOGY CO.,LTD.

We are WEE, We Enhance Efficiency

Year Established: 2000

Headquarter: Hongkong

Employees: 500

Products: General Purpose Rectifier, Fast Recovery Rectifier, Transient Voltage Suppressor, Schottky Rectifier, Switching Diode, Zener Diode...

Application: Automotive, Consumer, Computer, Lighting, Communication, Energy Harvesting, and Smart Grid...

Market: America, Europe, Asia, South Africa and Mid. East...

Advantages: Considerate Service, cCompetitive Offer, Credible Quality & Lead Time...

Catalogue: http://www.weediode.com/zb_users/upload/2020/10/WEETechnologyCompanyLimitedCatalogueDiodeRectifierTransistor.pdf

Presentation: http://www.weediode.com/zb_users/upload/2021/1/WEE-Technology-Company-Limited-Presentation.pdf

REACH: http://www.weediode.com/zb_users/upload/2021/2/WEE-Technology-Diodes-Rectifiers-REACH-2019.pdf

ROHS: http://www.weediode.com/zb_users/upload/2021/2/WEE-Technology-Diodes-Rectifiers-RoHS-II-2019.pdf

Website: www.weetcl.com

Wechat: WEETCHINA

Skype, Email: info@weediode.com

Written by WEE Technology Company Limited

Read More

WEET P6KE13CA P6KE18A P6KE24CA P6KE47A DO-15 AMMO TVS 600W Axial Lead Transient Suppression Diode

There are always some new stock of diodes, MLCC, tantalum capacitors, first come first served.

DO-15 600W P6KE Series P6KE6.8CA THRU P6KE600CA Transient Voltage Suppressor TVS
Datasheet: https://www.weetcl.com/pdf/WEET_DO15_P6KE_Series.pdf




Other Strongest TVS:
SMA 400W SMAJ Series SMAJ5.0CA THRU SMAJ440CA Transient Voltage Suppressor TVS
Datasheet: https://www.weetcl.com/pdf/WEET_SMA_SMAJ_Series.pdf

SMB 600W SMBJ Series SMBJ5.0CA THRU SMBJ440CA Transient Voltage Suppressor WEET TVS
Datasheet: https://www.weetcl.com/pdf/WEET_SMB_SMBJ_Series.pdf

DO-27 1500W 1.5KE Series 1.5KE6.8CA THRU 1.5KE440CA Transient Voltage Suppressor WEET TVS
Datasheet: https://www.weetcl.com/pdf/WEET_DO27_1.5KE_Series.pdf


Wechat: WEETCHINA
Skype, Email: info@weediode.com
more product support: https://weetcl.com/Products/

Read More

WEET New Stock for Urgent Demands Diode Rectifier P6KE24CA DO-15 SS36 DO-214AC CA45 Capacitors

WEE Technology Company Limited
We are WEE, We Enhance Efficiency
Manufacturer of Diode Rectifier, Bridge Rectifier, Transistor


For urgent demands of diode rectifiers, tantalum capacitors and ceramic capacitors, please contact us without hesitation.

The market supply of raw and processed materials of Schottky Diodes is extremely tensive, we are unable to continuously and efficiently supply it either. We will update once the supply turns normal.


NO.

WEET   DESCRIPTION

MPQ

MOQ


WTB: CA45 SMD Tantalum Capacitors Standard


https://www.weetcapacitor.com/Datasheet/WEET-WTB-CA45-SMD-Chip-Tantalum-Capacitors-Standard.pdf

1

68uF 25V +/-10% E case TapeReel

400PCS/REEL

2,000

2

68uF 25V +/-10% D case TapeReel

500PCS/REEL

2,500

3

15uF 35V +/-10% D case TapeReel

500PCS/REEL

2,500

4

47uF 35V +/-10% E case TapeReel

400PCS/REEL

2,000

5

more goods of WTB serie




WCD: SMD MLCC Ceramic Capacitors


https://www.weetcapacitor.com/Datasheet/WEET-WCD-Chip-SMD-4VDC-to-50VDC-MLCC-Mono-Capacitors-Multilayer.pdf

1

100nF 50V 0805 X7R +/-10% TapeReel

4KPCS/REEL

40,000

2

1uF 50V 0805 X7R +/-10% TapeReel

2KPCS/REEL

20,000

3

more goods of WCD serie




Diode Rectifiers


http://www.weediode.com/DATASHEETS.html

1

S1M DO-214AC TapeReel

2KPCS/REEL

20,000

2

1N5408 DO-27 Ammo

1.25KPCS/AMMO

12,500

3

SS16 DO-214AC TapeReel

5KPCS/REEL

30,000

4

K14 SOD-123FL TapeReel

3KPCS/REEL

30,000

5

ES1D DO-214AC TapeReel

5KPCS/REEL

30,000

6

SS36 DO-214AC TapeReel

5KPCS/REEL

30,000

7

P6KE24CA  DO-15 Ammo

2KPCS/AMMO


8



Wechat: WEETCHINA

Skype, Email: info@weediode.com

more product support: https://weetcl.com/Products/

Read More

WEET 10A 1000V GPP Bridge Rectifiers KBPC1010 Used in Power Circuit Rectification Products LED Light

WEET 10A 1000V GPP Bridge Rectifiers KBPC1010 Used in Power Circuit Rectification Products, Switching Power Supply, Power Adapter, LED Light Source Circuit, Charger,  Refrigerator, Air Conditioner, TV, Vehicle Rectifier, Electromechanical Equipment.


Functions of bridge rectifier KBPC1010: AC input at the front end of rectifier bridge and DC output at the back end convert AC to DC, so as to realize the use of electric energy in the circuit. The bridge connection is adopted in the rectifier bridge, and the theoretical conversion rate is 100%.


The meaning of 1010 in KBPC1010 bridge rectifier:

The first "10" is the forward current (rated current) of the full bridge;

The second "10" is withstand voltage 1000V (maximum reverse voltage, digital * 100 times = 1000V)


Price is only an indicator in the process of purchasing products or services. It's not so considerate if only compare prices. Price, quality, service and word of mouth need to be considered together.


KBPC1010 single phase square bridge rectifier parameter specification:

Current: 10A; Voltage: 1000V

Application: mainly used in power circuit rectification products, switching power supply, power adapter, LED light source circuit, charger, refrigerator, air conditioner, TV, household appliances, small appliances and other related products, vehicle rectifier, electromechanical equipment etc..

Skype, Email: info@weediode.com

WEE Technology Company Limited

Datasheets: http://www.weediode.com/DATASHEETS.html

Read More

WEET Leaded DO-27 DO-201AD SF51G SF52G SF53G SF54G SF55G SF56G SF58G Ultra-Fast Recovery Rectifiers

Ultra-Fast Recovery Rectifiers 5A 50-600V:


SF51,SF52,SF53,SF54,SF55,SF56,SF58

Package: DO-27   /  DO-201AD

Packing: Ammo 1.25K  /  Bulk 0.25K

Datasheet: http://www.weediode.com/zb_users/upload/2021/3/WEET_DO27_SF51_THRU_SF58.pdf


SF51G,SF52G,SF53G,SF54G,SF55G,SF56G,SF58G

Package: DO-27   /  DO-201AD

Packing: Ammo 1.25K  /  Bulk 0.25K

Datasheet: http://www.weediode.com/zb_users/upload/2021/3/WEET_DO27_SF51G_THRU_SF58G.pdf


Super fast speed switching speed

Low forward voltage drop

Low leakage current

High forward surge capability

High reliability

High temperature soldering guaranteed

Skype, Email: info@weediode.com

WEE Technology Company Limited

Datasheets: http://www.weediode.com/DATASHEETS.html

Read More

MELF DO-213AB LL-34 SM4001 SM4007 MiniMELF LL-34 SOD-80 DO-213AA LL4148 LL4448 LLDB3 BZV55C2V4 ZMM75

SMD Diode Rectifier

MELF / DO-213AB / DL-41 / LL-41 LL-34, SM4001 Thru SM4007.

Mini-MELF / LL-34 / SOD-80 / DO-213AA, LL4148, LL4448, LLDB3, BZV55C2V4 Thru BZV55C75, ZMM1 Thru ZMM75.


MELF / DO-213AB / DL-41 / LL-41 TapeReel 5KPCS/REEL


GLASS PASSIVATED SILICON RECTIFIERS:

SM4001 Thru SM4007

Datasheet: http://www.weediode.com/zb_users/upload/2021/6/WEET_Melf_SM4001_THRU_SM4007.pdf


Mini-MELF / LL-34 / SOD-80 / DO-213AA TapeReel 2.5KPCS/REEL


High Speed Switching Diode:

LL4148

Datasheet: http://www.weediode.com/zb_users/upload/2021/6/WEET_LL34_LL4148.pdf

LL4448


Bi-directional Trigger Diode:

LLDB3,DB3


Silicon Planar zener Diodes:

BZV55C2V4 Thru BZV55C75

Datasheet: http://www.weediode.com/zb_users/upload/2021/6/WEET_LL34_BZV55C2V4_THRU_BZV55C75.pdf

BZV55C2V4

BZV55C2V7

BZV55C3V0

BZV55C3V3

BZV55C3V6

BZV55C3V9

BZV55C4V3

BZV55C4V7

BZV55C5V1

BZV55C5V6

BZV55C6V2

BZV55C6V8

BZV55C7V5

BZV55C8V2

BZV55C9V1

BZV55C10V

BZV55C11V

BZV55C12V

BZV55C13V

BZV55C15V

BZV55C16V

BZV55C18V

BZV55C20V

BZV55C22V

BZV55C24V

BZV55C27V

BZV55C30V

BZV55C33V

BZV55C36V

BZV55C39V

BZV55C43V

BZV55C47V

BZV55B2V4

BZV55B2V7

BZV55B3V0

BZV55B3V3

BZV55B3V6

BZV55B3V9

BZV55B4V3

BZV55B4V7

BZV55B5V1

BZV55B5V6

BZV55B6V2

BZV55B6V8

BZV55B7V5

BZV55B8V2

BZV55B9V1

BZV55B10V

BZV55B11V

BZV55B12V

BZV55B13V

BZV55B15V

BZV55B16V

BZV55B18V

BZV55B20V

BZV55B22V

BZV55B24V

BZV55B27V

BZV55B30V

BZV55B33V

BZV55B36V

BZV55B39V

BZV55B43V

BZV55B47V


Silicon Planar zener Diodes:

ZMM1 Thru ZMM75

Datasheet: http://www.weediode.com/zb_users/upload/2021/6/WEET_LL34_ZMM1_THRU_ZMM75.pdf

ZMM2V4

ZMM2V7

ZMM3V0

ZMM3V3

ZMM3V6

ZMM3V9

ZMM4V3

ZMM4V7

ZMM5V1

ZMM5V6

ZMM6V2

ZMM6V8

ZMM7V5

ZMM8V2

ZMM9V1

ZMM10V

ZMM11V

ZMM12V

ZMM13V

ZMM15V

ZMM16V

ZMM18V

ZMM20V

ZMM22V

ZMM24V

ZMM27V

ZMM30V

ZMM33V

ZMM36V

ZMM39V

ZMM43V

ZMM47V

Skype, Email: info@weediode.com

WEE Technology Company Limited

Datasheets: http://www.weediode.com/DATASHEETS.html

Read More

WEET KBPC3510 Bulk Box Packing Single Phase Bridge Rectifier ISO ROHS REACH KBPC35005-KBPC3508

KBPC35005-KBPC3510 Datasheet: http://www.weediode.com/zb_users/upload/2021/3/WEET_KBPC35005_THUR_KBPC3510.pdf

Bridge Rectifier Diode, Single Phase, 1 kV, 35 A, Module, 1.2 V, 4 Pins

KBPC35005-KBPC3510: single-phase Bridge Rectifier with diffused junction and metal case;
Low Power Loss and High Efficiency;
Electrically Isolated Metal Case for Maximum Heat Dissipation;
Through Hole with #10 Screw Mounting;
Case to Terminal Isolation Voltage of 2500V.

More popular bridge rectifiers:
KBU4005-KBU410 http://www.weediode.com/zb_users/upload/2021/3/WEET_KBU4005_THRU_KBU410.pdf

KBPC35005-KBPC3510 http://www.weediode.com/zb_users/upload/2021/3/WEET_KBPC35005_THUR_KBPC3510.pdf
KBPC25005W-KBPC2510W http://www.weediode.com/zb_users/upload/2021/3/WEET_KBPC25005W_THUR_KBPC2510W.pdf
KBPC10005-KBPC1010 http://www.weediode.com/zb_users/upload/2021/3/WEET_KBPC10005_THUR_KBPC1010.pdf

KBP3005-KBP310 http://www.weediode.com/zb_users/upload/2021/3/WEET_KBP3005_THUR_KBP310.pdf
KBP2005-KBP210 http://www.weediode.com/zb_users/upload/2021/3/WEET_KBP2005_THUR_KBP210.pdf

KBL6005-KBL610 http://www.weediode.com/zb_users/upload/2021/3/WEET_KBL6005_THRU_KBL610.pdf

KBJ10005-KBJ1010 http://www.weediode.com/zb_users/upload/2021/3/WEET_KBJ10005_THUR_KBJ1010.pdf
KBJ6005-KBJ610 http://www.weediode.com/zb_users/upload/2021/3/WEET_KBJ6005_THRU_KBJ610.pdf

GBU15005-GBU1510 http://www.weediode.com/zb_users/upload/2021/3/WEET_GBU15005_THRU_GBU1510.pdf
GBU8005-GBU810 http://www.weediode.com/zb_users/upload/2021/3/WEET_GBU8005_THRU_GBU810.pdf
GBU4005-GBU410 http://www.weediode.com/zb_users/upload/2021/3/WEET_GBU4005_THUR_GBU410.pdf

GBPC50005-GBPC5010 http://www.weediode.com/zb_users/upload/2021/3/WEET_GBPC50005_THRU_GBPC5010.pdf
GBPC35005W-GBPC3510W http://www.weediode.com/zb_users/upload/2021/3/WEET_GBPC35005W_THUR_GBPC3510W.pdf
GBPC15005-GBPC1510 http://www.weediode.com/zb_users/upload/2021/3/WEET_GBPC15005_THRU_GBPC1510.pdf

GBP GBP3005-GBP310 http://www.weediode.com/zb_users/upload/2021/3/WEET_GBP_GBP3005_THRU_GBP310.pdf
GBP GBP2005-GBP210 http://www.weediode.com/zb_users/upload/2021/3/WEET_GBP_GBP2005_THRU_GBP210.pdf

GBJ25005-GBJ2510 http://www.weediode.com/zb_users/upload/2021/3/WEET_GBJ25005_THUR_GBJ2510.pdf
GBJ15005-GBJ1510 http://www.weediode.com/zb_users/upload/2021/3/WEET_GBJ15005_THUR_GBJ1510.pdf
GBJ601-GBJ610 http://www.weediode.com/zb_users/upload/2021/3/WEET_GBJ601_THRU_GBJ610.pdf

product support: https://weetcl.com/Products/
Skype, Email: info@weediode.com
Written by WEE Technology Company Limited

Read More

WEET W1 W2 DIODE ZENER 0.2W-0.5W BZT52C2V7 BZT52C3V0 SOD-123 BZT52C2V7S BZT52C3V0S SOD-323

Marking W1 represents Part no. BZT52C2V7 SOD-123, BZT52C2V7S SOD-323
Marking W2 represents Part no. BZT52C3V0 SOD-123, BZT52C3V0S SOD-323

DIODE, ZENER 0.5W SOD-123 BZT52C serie datasheet: http://www.weediode.com/zb_users/upload/2021/3/WEET_SOD123_BZT52C2V4_THRU_BZT52C43.pdf

Marking Code

Part no.

Part no.

WY

BZT52C2V0S


WX

BZT52C2V4S

BZT52C2V4

W1

BZT52C2V7S

BZT52C2V7

W2

BZT52C3V0S

BZT52C3V0

W3

BZT52C3V3S

BZT52C3V3

W4

BZT52C3V6S

BZT52C3V6

W5

BZT52C3V9S

BZT52C3V9

W6

BZT52C4V3S

BZT52C4V3

W7

BZT52C4V7S

BZT52C4V7

W8

BZT52C5V1S

BZT52C5V1

W9

BZT52C5V6S

BZT52C5V6

WA

BZT52C6V2S

BZT52C6V2

WB

BZT52C6V8S

BZT52C6V8

WC

BZT52C7V5S

BZT52C7V5

WD

BZT52C8V2S

BZT52C8V2

WE

BZT52C9V1S

BZT52C9V1

WF

BZT52C10S

BZT52C10

WG

BZT52C11S

BZT52C11

WH

BZT52C12S

BZT52C12

WI

BZT52C13S

BZT52C13

WJ

BZT52C15S

BZT52C15

WK

BZT52C16S

BZT52C16

WL

BZT52C218S

BZT52C218

WM

BZT52C20S

BZT52C20

WN

BZT52C22S

BZT52C22

WO

BZT52C24S

BZT52C24

WP

BZT52C27S

BZT52C27

WQ

BZT52C30S

BZT52C30

WR

BZT52C33S

BZT52C33

WS

BZT52C36S

BZT52C36

WT

BZT52C39S

BZT52C39

WU/WY


BZT52C43

WV/WZ


BZT52C47

WW/X1


BZT52C51

Product Datasheets: http://www.weediode.com/WEET_DATASHEETS_Diode_Bridge.html
Skype, Email: info@weediode.com
Written by WEE Technology Company Limited

Read More

WEET 2021 Spring Festival Holiday Notice 1st-22nd Feb. Wish a Safe Healthy Prosperous New Year

WEET closes on 1st-22nd Feb., but sales are online 24hours on email, feel free to shoot us any inquiries.

Chinese New Year, also known as Lunar New Year or Spring Festival, is China's most important festival. It is time for families to be together.

Chinese New Year 2021 falls on Friday, February 12, 2021, beginning a year of the Ox.

The important dates during the period of Chinese New Year 2021:

February 4th, 2021    December 23rd    Little Year
February 11th, 2021    December 30th    Chinese New Year's Eve
February 12th, 2021    January 1st    Chinese New Year (Spring Festival)
February 26th, 2021    January 15th    Lantern Festival

Wish you in the New Year Good Health, Safety, Full Life, Career Advancement, Sunny Mood, Rich Fortune, Happy Family, Happy New Year!

product support: https://weetcl.com/Products/
Skype, Email: info@weediode.com
Written by WEE Technology Company Limited

Read More

WEET MOSFETs N-P Channel TO-251-4R TO-252-4R TO-220A Insulated TO-220B Non-Insulaed TO-220F Insulate

MOSFET stands for Metal Oxide Silicon Field Effect Transistor or Metal Oxide Semiconductor Field Effect Transistor. This is also called as IGFET meaning Insulated Gate Field Effect Transistor. The FET is operated in both depletion and enhancement modes of operation.

What are MOSFETs used for?
The MOSFET (Metal Oxide Semiconductor Field Effect Transistor) transistor is a semiconductor device that is widely used for switching purposes and for the amplification of electronic signals in electronic devices.

How do MOSFETs work?
In general, the MOSFET works as a switch, the MOSFET controls the voltage and current flow between the source and drain. The working of the MOSFET depends on the MOS capacitor, which is the semiconductor surface below the oxide layers between the source and drain terminal.

Are all MOSFETs the same?
All MOSFETs are FETs, not all FETs are MOSFETs. But the term is so common that things that are not actually MOSFETs are still called "MOSFETs", so there isn't really much difference; the terms are kind of interchangeable.

What are the types of MOSFETs?
There are two classes of MOSFETs. There is depletion mode and there is enhancement mode. Each class is available as n- or a p-channel, giving a total of four types of MOSFETs. Depletion mode comes in an N or a P and an enhancement mode comes in an N or a P.

Why N channel is better than P channel Mosfet?
The N-channel MOSFET has several advantages over the P-channel MOSFET. For example, the N-channel majority carriers (electrons) have a higher mobility than the P-channel majority carriers (holes). Because of this, the N-channel transistor has lower RDS(on) and gate capacitance for the same die area.

Is N channel NPN or PNP?
An N-Channel mosfet needs a positive Gate - Source voltage to conduct. An P-Channel mosfet needs a negative Gate - Source voltage to conduct. An NPN transistor needs a positive Base - Emitter current to conduct. An PNP transistor needs a negative Base - Emitter current to conduct.

Is 2N7000 NPN or PNP?
2N7000 is a N-channel mosfet. NPN or PNP indicated BJT type transistor. unlike BJTs mosfets are symmetrical devices and S and D is actually defined by connection of the bulk. in case of 3-pin packaged mosfets, you no longer have control of how the bulk is connected so make sure to verify pinout using correct datasheet.


product support: https://weetcl.com/Products/
Skype, Email: info@weediode.com
Written by WEE Technology Company Limited

Read More

WEET BC368 NPN BC369 PNP Amplifier Transistors Through Hole TO-92 ISO ROHS REACH Certified

BC368 NPN:
Product Category: Bipolar Transistors - BJT
Mounting Style: Through Hole
Package / Case: TO-92-3
Transistor Polarity: NPN
Configuration: Single
Collector- Emitter Voltage VCEO Max: 0 V
Collector- Base Voltage VCBO: 25 V
Emitter- Base Voltage VEBO: 5 V
Collector-Emitter Saturation Voltage: 0.5 V
Maximum DC Collector Current: 1 A
Pd - Power Dissipation: 625 mW
Gain Bandwidth Product fT: 65 MHz
Minimum Operating Temperature: - 55 C
Maximum Operating Temperature: + 150 C
DC Current Gain hFE Max: 50 at 5 mA, 10 V
Height: 4.01 mm
Length: 4.77 mm
Technology: Si
Width: 2.41 mm
Continuous Collector Current: 2 A
Product Type: BJTs - Bipolar Transistors
Subcategory: Transistors
Unit Weight: 0.46g

BC369 PNP:
Product Category: Bipolar Transistors - BJT
Mounting Style: Through Hole
Package / Case: TO-92-3
Transistor Polarity: PNP
Configuration: Single
Collector- Emitter Voltage VCEO Max: 20 V
Collector- Base Voltage VCBO: 25 V
Emitter- Base Voltage VEBO: 5 V
Collector-Emitter Saturation Voltage: - 0.5 V
Maximum DC Collector Current: 1 A
Pd - Power Dissipation: 625 mW
Gain Bandwidth Product fT: 65 MHz
Minimum Operating Temperature: - 55 C
Maximum Operating Temperature: + 150 C
DC Current Gain hFE Max: 50 at 5 mA, 10 V
Height: 4.01 mm
Length: 4.77 mm
Technology: Si
Width: 2.41 mm
Continuous Collector Current: 1.5 A
Product Type: BJTs - Bipolar Transistors
Subcategory: Transistors
Unit Weight: 0.46g

product support: https://weetcl.com/Products/
Skype, Email: info@weediode.com
Written by WEE Technology Company Limited

Read More

WEET Best Wishes to a Brighter and Happier New Year 2021

Let the old year-end and the New Year begin with the warmest of aspirations. Happy New Year!

Nights will be dark, but days will be light, wishing your life to be always bright. Happy New Year!

May this New Year bring you much joy and fun. May you find peace, love, and success. Happy New Year!


product support: https://weetcl.com/Products/
Skype, Email: info@weediode.com
Written by WEE Technology Company Limited

Read More

WEET Square Bridge Rectifiers 50A 1000V KBPC5010 Single Phase Bridge Through Hole KBPC50005 KBPC5001

WEET Square Bridge Rectifiers 50A 1000V KBPC5010 Single Phase Bridge Through Hole KBPC50005 KBPC5001 KBPC5002 KBPC5004 KBPC5006 KBPC5008

A high quality bridge rectifier was used to convert the AC input to the DC output.
Welded to the top, the inside is good, ensuring more stable performance.
The base is small, the overcurrent capacity is large, the heat dissipation is good, and the voltage drop is small.
These high power, high frequency power bridge rectifiers are widely used in the United States, Mexico, Canada, Poland, Germany, England, Spain, Russia, Ukraine, Turkey, Japan, Korea.

KBPC5010
Bridge Rectifier Diode, Full Bridge, KBPC Series, Single Phase, 1000V, 50A, Module, 4 Pins, Efficiency 100%

Product Overview
The KBPC5010 is a single-phase Bridge Rectifier with diffused junction and metal case.
Low Power Loss and High Efficiency
Electrically Isolated Metal Case for Maximum Heat Dissipation
Through Hole with #10 Screw Mounting
Case to Terminal Isolation Voltage of 2500V

Applications
Mains Rectification

The complete serie KBPC50005 KBPC5001 KBPC5002 KBPC5004 KBPC5006 KBPC5008 KBPC5010

50A 50V Bridge Rectifier KBPC50005
50A 100V Bridge Rectifier KBPC5001
50A 200V Bridge Rectifier KBPC5002
50A 400V Bridge Rectifier KBPC5004
50A 600V Bridge Rectifier KBPC5006
50A 800V Bridge Rectifier KBPC5008
50A 1000V Bridge Rectifier KBPC5010

more product support: https://weetcl.com/Products/
Skype, Email: info@weediode.com
Written by WEE Technology Company Limited

Read More

WEET Glass Passivated Square Bridge Rectifiers 35A 1000V GBPC3510 Cross Vishay, Diodes, Comchip, MCC

WEE Technology Company Limited
We are WEE, We Enhance Efficiency
Manufacturer of Diode Rectifier, Bridge Rectifier, Transistor


WEET Glass Passivated Square Bridge Rectifiers 35A 1000V GBPC3510 Cross Vishay Semiconductors, Diodes Incorporated, ON Semiconductor, Comchip Technology, MCC, GeneSiC...

GBPC3510 Features:
Integrally molded heatsink provided very low thermal resistance for maximum heat dissipation
Surge overload rartings from 300 A to 400 A
Isolated voltage from case to lead over 2500 V
Terminals Finish Material - Silver (solderable per MIL-STD-202, Method 208 for the wire type GBPC-W package), - Nickel for GBPC package

GBPC3510 Applications:
General purpose use in AC/DC bridge full wave rectification for power supply, home appliances, office equipment, industrial automation applications.

Same serie:
GBPC12005, GBPC1201, GBPC1202, GBPC1204, GBPC1206, GBPC1208, GBPC1210.
GBPC15005, GBPC1501, GBPC1502, GBPC1504, GBPC1506, GBPC1508, GBPC1510.
GBPC25005, GBPC2501, GBPC2502, GBPC2504, GBPC2506, GBPC2508, GBPC2510.
GBPC35005, GBPC3501, GBPC3502, GBPC3504, GBPC3506, GBPC3508, GBPC3510.
GBPC50005, GBPC5001, GBPC5002, GBPC5004, GBPC5006, GBPC5008, GBPC5010.

GBPC12, GBPC15, GBPC25, GBPC35 GBPC50 stand for Maximum average forward rectified output current 12A, 15A, 25A, 35A.

SYMBOL 005, 01, 02, 04, 06, 08, 10 stand for Maximum repetitive peak reverse voltage and Maximum DC blocking voltage 50V, 100V, 200V, 400V, 600V, 800V, 1000V.

more product support: https://weetcl.com/Products/
Skype, Email: info@weediode.com
Written by WEE Technology Company Limited

Read More

WEET Square Bridge Rectifiers 50A 1000V BR5010 Silicon Bridge Through Hole BR50005 BR5002-BR5008

WEE Technology Company Limited
We are WEE, We Enhance Efficiency
Manufacturer of Diode Rectifier, Bridge Rectifier, Transistor


WEET Square Bridge Rectifiers 50A 1000V BR5010 Silicon Bridge Through Hole BR50005 BR5001 BR5002 BR5004 BR5006 BR5008

Our company adheres to the principle of honesty, all the products sold are in our own inventory, brand new original, real shots, all descriptions are true descriptions, and there is no shoddy.

The model BR5010, weight 955g, application range is motor, the rectifier element is a single-phase bridge, the power characteristic is medium power, the frequency characteristic is low frequency, AC input voltage is 380V, DC output voltage is 1000V, and DC output current is 50A, the forward peak voltage is 1000V, the reverse repetitive peak voltage is 1000V, the reverse repetitive peak current is 150mA, the insulation voltage is 3V, and the operating junction temperature is 115 ℃, the efficiency is 99%.

BR50005 BR5001 BR5002 BR5004 BR5006 BR5008 BR5010 Application Honda, Huandai, Huizhong, Hummer, Infiniti, Jaguar, Jeep...

The same seire Square Bridge Rectifiers 35A Silicon Bridge Through Hole 50V BR35005, 100V BR3501, 200V BR3502, 400V BR3504, 600V BR3506, 800V BR3508, 1000V BR3510.

WEE Technology Company Limited is a marketing office established in Hong Kong since 2000. We are specialized in manufacturing diodes and bridge rectifiers, both in surface mount and through hole Type, which including Zener Diodes,Switching Diodes,Bridge Rectifiers,General Rectifier Diodes,Fast Recovery Rectifiers,High Efficient Rectifiers,Schottey Barrier Rectifiers,Transient Voltage Suppessors,Super Fast Recovery Rectifiers,Small Signal Transistors.

WEE Jiangsu factory was set up in 2001, which specializing in diodes and rectifiers products, mainly including SMAF, SMA-J, SMA, SMB, SMC, DO-15, DO-27, DO-41, A-1, R-6 package and so on. WEE Anhui factory is the expertise in bridge rectifiers since 1998. Bridge rectifiers current range from 0.5A to 50A, voltage range from 50V to 1000V, most common package are MINIDIP, DB,WOM,MBS, MBF, KBP, GBP, GBL, S25VB, TO-220, KBL, KBU, GBU, GBJ, KBPC, GBPC and so on.All of our products are meeting RoHS 2.0 and Reach standard.

Current Export Market: North America, South America, Western Europe, Eastern Europe, Eastern Asia, Southeast Asia, Mid East, Africa..

Number of Employees: 401 - 500 People

more product support: https://weetcl.com/Products/
Skype, Email: info@weediode.com
Written by WEE Technology Company Limited

Read More

WEET Square Bridge Rectifier 35A 1000V BR3510 Single Phase Bridge Through Hole BR35005-BR3508

WEE Technology Company Limited
We are WEE, We Enhance Efficiency
Manufacturer of Diode Rectifier, Bridge Rectifier, Transistor

WEET Square Silicon Bridge Rectifiers 35A 1000V BR3510 Single Phase Bridge Through Hole BR35005 BR3501 BR3502 BR3504 BR3506 BR3508

FEATURES:
Surge overload:240~500 amperes peak
Low forward voltage drop
Mounting position: Any
Electrically  isolated  base:2000 Volts
Solderable 0.25" FASTON terminals
Materials used carries U/L recognition

BR10/15/25/35/50A W -G SERIES"-G" : RoHS Device

REVERSE VOLTAGE-50 to 1000V
FORWARD CURRENT-10/15/25/35/50A

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Rating at 25°C ambient temperature unless otherwise specified.
Resistive or inductive load 60HZ.
For capacitive load current by 20%

The same seire Square Bridge Rectifiers:

10A Silicon Bridge Through Hole 50V BR10005,  100V BR1001, 200V BR1002, 400V BR1004, 600V BR1006, 800V BR1008
15A Silicon Bridge Through Hole 50V BR15005,  100V BR1501, 200V BR1502, 400V BR1504, 600V BR1506, 800V BR1508
25A Silicon Bridge Through Hole 50V BR25005,  100V BR2501, 200V BR2502, 400V BR2504, 600V BR2506, 800V BR2508
50A Silicon Bridge Through Hole 50V BR50005,  100V BR5001, 200V BR5002, 400V BR5004, 600V BR5006, 800V BR5008

Contact us to get Pricing, Inventory, Delivery & Lifecycle Information.

more product support: https://weetcl.com/Products/
Skype, Email: info@weediode.com
Written by WEE Technology Company Limited

Read More

WEET Single Phase Square Bridge Rectifiers 1000V 50A KBPC5010 BR5010 35A GBPC3510 BR3510

WEE Technology Company Limited
We are WEE, We Enhance Efficiency
Manufacturer of Diode Rectifier, Bridge Rectifier, Transistor


WEET mainly deals in Bridge Rectifiers and Diode Rectifiers. The company adheres to the business philosophy of "customer first, forge ahead" , to provide customers with superior services. Welcome to patronize! The strong product is Large Size Single Phase Bridge Rectifiers, TVS Transient Voltage Suppressors. We always insist on honesty and benefit to customers, and insist on using our sincere services to impress customers. If you are interested in our products, you can directly submit purchasing information through email. Welcome friends from all industries to guide and negotiate business.

Popular Single Phase Bridge Rectifiers Products List:

50.0 AMPS GBPC50005 THRU GBPC5010 (GBPC50005, GBPC5001, GBPC5002, GBPC5004, GBPC5006, GBPC5008, GBPC5010) Bridge Rectifiers GBPC GBPC50005 THRU GBPC5010
35.0 AMPS GBPC35005W THUR GBPC3510W (GBPC35005W, GBPC3501W, GBPC3502W, GBPC3504W, GBPC3506W, GBPC3508W, GBPC3510W) Bridge Rectifiers GBPC GBPC35005W THUR GBPC3510W
15.0 AMPS GBPC15005 THRU GBPC1510 ( GBPC15005, GBPC1501, GBPC1502, GBPC1504, GBPC1506, GBPC1508, GBPC1510 ) Bridge Rectifiers GBPC GBPC15005 THRU GBPC1510

35.0 AMPS KBPC35005 THUR KBPC3510(KBPC35005W, KBPC3501W, KBPC3502W, KBPC3504W, KBPC3506W, KBPC3508W, KBPC3510W) Bridge Rectifiers KBPC KBPC35005 THUR KBPC3510
10.0 AMPS KBPC10005 THUR KBPC1010K ( KBPC10005, KBPC1001, KBPC1002, KBPC1004, KBPC1006, KBPC1008, KBPC1010 ) Bridge Rectifiers KBPC KBPC10005 THUR KBPC1010K

25.0 AMPS GBJ25005 THUR GBJ2510 (GBJ25005, GBJ2501, GBJ2502, GBJ2504, GBJ2506, GBJ2508, GBJ2510) Glass Passivated Bridge Rectifiers GBJ GBJ25005 THUR GBJ2510
15.0 AMPS GBJ15005 THUR GBJ1510 (GBJ15005, GBJ1501, GBJ1502, GBJ1504, GBJ1506, GBJ1508, GBJ1510) Glass Passivated Bridge Rectifiers GBJ GBJ15005 THUR GBJ1510
6.0 AMPS GBJ601 THRU GBJ610 (GBJ6005, GBJ601, GBJ602, GBJ604, GBJ606, GBJ608, GBJ610) Glass Passivated Bridge Rectifiers GBJ GBJ601 THRU GBJ610

10.0 AMPS KBJ10005 THUR KBJ1010 (KBJ10005, KBJ1001, KBJ1002, KBJ1004, KBJ1006, KBJ1008, KBJ1010) Glass Passivated Bridge Rectifiers KBJ KBJ10005 THUR KBJ1010
6.0 AMPS KBJ6005 THRU KBJ610 (KBJ6005, KBJ601, KBJ602, KBJ604, KBJ606, KBJ608, KBJ610) Glass Passivated Bridge Rectifiers KBJ KBJ6005 THRU KBJ610

15.0 AMPS GBU15005 THRU GBU1510(GBU15005, GBU1501, GBU1502, GBU1504, GBU1506, GBU1508, GBU1510) Bridge Rectifiers


more product support: https://weetcl.com/Products/
Skype, Email: info@weediode.com
Written by WEE Technology Company Limited

Read More

WEET Flat Bridge Rectifiers GBJ 10A 1000V GBJ1010 Single Phase Bridge Through Hole GBJ10005-GBJ1008

WEE Technology Company Limited
We are WEE, We Enhance Efficiency
Manufacturer of Diode Rectifier, Bridge Rectifier, Transistor

Generally speaking, we call the components directly plugged into the circuit board as Dip components. The corresponding components are SMD components. There are some internal bridge rectifiers with large power and capacity that require additional heat sinks and special installation places. Therefore, the Dip bridge rectifier refers to the bridge rectifier that is directly plugged into the circuit board. Generally, the power is not very large. Most of the common ones are <20A, and a heat sink can be added to the circuit board.

Common classifications of bridge rectifiers are generally directly classified by their withstand voltage and allowable current.

Bridge rectifiers are generally used in circuits that require AC (pulse) to DC conversion. Most electrical appliances are used. They are generally used in switching power supplies or power circuits of electrical appliance, low-power switching power supplies, chargers, power adapters, LED light rectifiers, electric fans, TV sets, indoor air conditioners and other related electrical products.

WEET adheres to the quality policy of "Keep improving, satisfying customers, pursuing excellence, and innovative development", with the goal of serving customers, continuous innovation, pursuit of excellence, and continuous improvement of product quality. Products are widely used in industries such as lighting, power adapters, computers, televisions, communication equipment, tablets, and small household appliances.

WEET provides customers with cost-effective products with excellent quality and cost competitiveness, and is committed to becoming one of the best manufacturers of semiconductor components.

WEET Flat Bridge Rectifiers GBJ 10A 1000V GBJ1010 Through Hole Single Phase Bridge
Same serie includes GBJ10005(50V) GBJ1001(100V) GBJ1002(200V) GBJ1004(400V) GBJ1006(600V) GBJ1008(800V)

more product support: https://weetcl.com/Products/
Skype, Email: info@weediode.com
Written by WEE Technology Company Limited

Read More

WEET Flat Bridge Rectifiers GBU 10A 1000V GBU1010 Single Phase Bridge Through Hole GBU10005 GBU1001

WEE Technology Company Limited
We are WEE, We Enhance Efficiency
Manufacturer of Diode Rectifier, Bridge Rectifier, Transistor

WEET is a high-tech enterprise specializing in R&D, production and sales of semiconductor discrete devices. The company has introduced a full set of foreign advanced equipments and scientific management system, and its product quality enjoys a good reputation in domestic and overseas markets. WEET has passed the ISO9001:2015 quality management system, and all products comply with environmental protection ROHS, REACH, and halogen-free standards.

WEET product models are complete: General Purpose Rectifiers, High Efficiency Rectifiers, Ultra-Fast Recovery Rectifiers, Fast Recovery Rectifiers, Single Phase Bridge Rectifiers, Transient Voltage Suppressors, Schottey Barrier Rectifiers, High Speed Switching Diodes, Silicon Planar Zener Diodes, Small Signal Transistors etc. Package forms are: SOD-123, SOD-323, SOD-523, SMAF, SMBF, SMA, SMB, SMC, SOT-23, SOT-323, SOT-523, TO-220AB, DO-41, DO-15, DO-27, R-6, MBS, MBF, ABS, ABF, DBS, KBP, GBP, KBU, GBJ, GBU, KBL etc.

Products are widely used in mobile phone chargers, switching power supplies, LED lighting drive power supplies, smart meters, smart water meters, smart appliances, smart sockets, instrumentation, small home appliance control panels, 5G consumer electronics, etc.

GBU1010 GBU bridge rectifier is a rectifier device composed of two or four diodes.

The bridge stack has three types of half bridge,full bridge, and three-phase bridge, and there are two types of positive half bridge and negative half bridge.
The full bridge consists of four diodes with four lead-out pins.

The connection point of the cathodes of the two diodes is the "positive" of the full-bridge DC output terminal, and the connection point of the anodes of the two diodes is the "cathode" of the full-bridge DC output.

The half bridge is composed of two diodes with three lead-out pins.
The pins on both sides of the positive half-bridge are the anodes of the two diodes, that is, the AC input terminal; the middle pins are the cathodes of the two diodes, that is, the "positive" of the DC output terminal.
The negative poles of the two diodes on the pins on both sides of the negative half bridge are the AC input terminals; the middle pin is the anode of the two diodes, that is, the "negative" of the DC output terminal.

A positive half bridge and a negative half bridge can form a full bridge.

Example: WEET Flat Bridge Rectifiers GBU 10A 1000V GBU1010 Single Phase Bridge Through Hole GBU10005 GBU1001 GBU1002 GBU1004 GBU1006 GBU1008

more product support: https://weetcl.com/Products/
Skype, Email: info@weediode.com
Written by WEE Technology Company Limited

Read More

WEET Tells How to Measure the Quality of the Bridge Rectifier

WEE Technology Company Limited
We are WEE, We Enhance Efficiency
Manufacturer of Diode Rectifier, Bridge Rectifier, Transistor

WEET Tells How to Measure the Quality of the Bridge Rectifier

Take three-phase rectifier bridge as an example. With a digital meter, it is normal if there is a voltage drop of about 700mV during forward measurement. If the voltage drop is small, it will be broken down, and if the voltage drop is too large, it will be blown. No pressure drop is normal. Multimeters are also called multiplex meters, multimeters, three-meters, multi-meters, etc. They are indispensable measuring instruments in power electronics and other sectors. They generally measure voltage, current, and resistance as their main purpose.

The three-phase bridge rectifier is composed of 6 diodes in series and parallel, and each diode can be measured separately according to the method of measuring a single diode.

According to the display mode, multimeters are divided into pointer multimeters and digital multimeters. It is a multi-function, multi-range measuring instrument. Generally, a multimeter can measure DC current, DC voltage, AC current, AC voltage, resistance and audio level, etc. Some can also measure AC current, capacitance, inductance and semiconductor parameters (such as β), etc.

WEET Flat Bridge Rectifiers GBU 6A 1000V GBU610 Single Phase Bridge Through Hole GBU6005 GBU601 GBU602 GBU604 GBU606 GBU608

The bridge rectifier stack GBU6005-GBU610 is used in small current products: low-power switching power supplies, power adapters, LED light rectifiers, electric fans, televisions, indoor air conditioners, household appliances and other related electrical products. Our products are new, original and has good stability and reliability. Welcome to consult and sample for testing.

more product support: https://weetcl.com/Products/
Skype, Email: info@weediode.com
Written by WEE Technology Company Limited

Read More

WEET Measurement Method of Square, Flat, Round, Patch MINI Bridge Rectifier

WEE Technology Company Limited
We are WEE, We Enhance Efficiency
Manufacturer of Diode Rectifier, Bridge Rectifier, Transistor

Measurement method of Bridge Rectifier:

The measurement method of the rectifier bridge stack is to use a multimeter to measure.

Measurement method: when normal, the forward and reverse resistances of the two AC input terminals ("~") of the full bridge are both infinite; the forward resistance of the "+""-" input terminal is infinite, and the reverse resistance (connected with red pen) "+", black pen connected to "-" end) is about 20K. Assuming to check with a digital universal meter (diode) file, the red pen is connected to "-', the black test pen is connected to "+" is 0.8; two "~" are connected are about 0.4, the red pen is connected to "+", the black pen is connected to the other three pins It must be infinite, otherwise it is a damaged rectifier.

The rectifier full bridge is composed of four diodes with four lead-out pins: the connection point of the negative poles of the two diodes is the "positive" of the DC output end of the full bridge, and the connection point of the anodes of the two diodes is the "negative" of the DC output end of the full bridge. The half bridge is composed of two diodes with three lead-out pins.

The pins on both sides of the positive half-bridge are the anodes of the two diodes, that is, the AC input terminal; the middle pins are the cathodes of the two diodes, that is, the "positive" of the DC output terminal. The negative poles of the two diodes on the pins on both sides of the negative half bridge are the AC input terminals; the middle pin is the positive poles of the two diodes, that is, the "negative poles" of the DC output terminals.

1. The basic principle of the rectifier bridge stack: The rectifier bridge stack product is made of four rectifier silicon chips for bridge connection and externally packaged with insulating plastic. The high-power rectifier bridge is encapsulated with a zinc metal shell outside the insulating layer to enhance heat dissipation. There are many types of rectifier bridges: flat, round, square, bench-shaped (in-line and patch), etc. There are GPP and O/J structures.

The maximum rectified current ranges from 0.5A to 100A, and the maximum reverse peak voltage ranges from 50V to 1600V. The half bridge is to seal the half of the two diode bridge rectifiers together. Two half bridges can form a bridge rectifier circuit, and a half bridge can also form a full wave rectifier circuit with a center tap of the transformer.

The full bridge is composed of 4 rectifier diodes connected in the form of a bridge full-wave rectifier circuit and packaged as a whole. The forward current of the full bridge has various specifications such as 0.5A, 1A, 1.5A, 2A, 2.5A, 3A, 5A, 10A, 20A, 35A, 50A, etc. The withstand voltage (the highest reverse voltage) is 25V, 50V, 100V, 200V, 300V, 400V, 500V, 600V, 800V, 1000V and other specifications.

2. Package form There are four types of rectifier bridge packages: square bridge, flat bridge, round bridge, and patch MINI bridge. The main packages of square bridges are (BR3, BR6, BR8, GBPC, KBPC, KBPC-W, GBPC-W, MT-35 (three-phase bridge)); the main packages of flat bridges are (KBP, KBL, KBU, KBJ, GBU, GBJ, D3K); round bridges are mainly packaged (WOB, WOM, RB-1); SMD MINI bridges are mainly packaged (BDS, MBS, MBF, ABS).

The following is piture for Flat Bridge Rectifier GBJ 50A 1000V GBJ5010

more product support: https://weetcl.com/Products/
Skype, Email: info@weediode.com
Written by WEE Technology Company Limited

Read More
